Description
The Factory Workshop Manual for the Hitachi excavator. Includes detailed illustrations, instructions, and diagrams that facilitate step-by-step processes for the removal and installation, assembly and disassembly, servicing, inspection, repair, troubleshooting, tune-ups.
Pub.No: KM580E-01
Language: English
Pages: 730
Bookmarks
Searchable text
Upon successful payment, you shall promptly receive a PDF file delivered to your email.
Models
Hitachi Excavator
EX8
EX12
EX15
EX22
EX30
Contents
-SPECIFCATIONS
General Information
Dimensions and Weights
Fuels and Lubricants
Interchangeability
-UPPERSTRUCTURE
Outline
Tank
Pump Device
Swing Device
Pipings
Control Valve
Pilot Valve
Lock Valve
Solenoid Valve
Engine
-UNDERCARRIAGE
Component Location
Swing Bearing
Center Joint
Travel Device
Adjuster
-OPERATIONAL PERFORMANCE TEST
Introduction
Engine Test
Excavator Test
Hydraulic Component Test
-TROUBLESHOOTING
Diagnosing Procedure
Hydraulic System
Electrical System
