Description
The Factory Operators Manual for the Case tractor. Comprehensive guide designed to provide machinery users with essential information on the safe and efficient operation. This document covers various aspects such as setup procedures, maintenance, troubleshooting, and safety precautions. It aims to ensure operators can effectively use the machinery while minimising risks and maximising productivity. A must-have for any machinery owner or user, an Operator Manual is the key to unlocking the full potential of your equipment.
Pub.No: 9-24844
Language: English
Pages: 285
Searchable
Upon successful payment, you shall promptly receive a PDF file delivered to your email.
Models
Format: PDF
Language: English
Pages: 285
Number: 9-24844
Searchable: Yes
Model
Case IH Tractor
3210
3220
3230
4210
4220
4230
4240
Contents
TO THE OWNER
IDENTIFICATION NUMBERS
-SAFETY/DECALS
Intended Use
General Safety And Accident Prevention Regulations
Transporting Passengers
Operation
Leaving The Tractor
Implements
PTO Operation
Service
Basic Rule
Mounting And Dismounting The Tractor
Safety Decals
Roll Over Protective Structure (ROPS)
-INSTRUMENTS/CONTROLS
Digital Instrument Cluster
Operating Controls (XL Cab, LP Cab, Platform)
Operating Controls (Non-Cab Tractors)
Operators Seat
-OPERATING INSTRUCTIONS
Before Starting The Engine
Service Indicator Lamps And Gauges
Run In Procedure
Seat Belt (If Equipped)
Normal Starting Procedure
Stopping The Engine
Cold Temperature Operation
Towing The Tractor
How To Transport The Tractor
Transmission Operating Instructions
Differential Lock
MFD Operation
Cab Air Flow Arrangements (XL Cab)
Air Conditioner Operation
Cab Air Flow Arrangements (Low Profile Cab)
Power Takeoff (PTO)
Drawbar Operation
Combined Auto Hitch And 2 Piece Drawbar
Height Adjustable Trailer Hitch
Trailer/Implement Drawbar Dimensions
Tractor Warning Lamps And Direction Turn Signals
-FIELD OPERATION
Drawbar Preparation
Three Point Hitch System Preparation
Three Point Hitch Operation
Front Hitch Preparation
Remote Hydraulics Operation
Auxiliary Power Connections
Digital Instrument Cluster Programming
Hourmeter
Implement Monitor
ROPS Frame
-TIRES/WHEELS/SPACING/BALLAST
Tire And Wheel Equipment
Tire Pressures And Load Capacities
Tire And Wheel Service
Front To Rear Tire Size Combinations
Front Wheel Tread Positions
Rear Wheel Tread Positions
Toe-In Setting
Wheel Bolt Torques
MFD Axle Steering Stop Adjustment
MFD Axle Oscillation Stops
Front Wheel Fenders
Tractor Ballast
-LUBRICATION/FILTERS/FLUIDS
Hourmeter
Lubrication/Maintenance Chart
Hood And Side Covers
Grease Points
Capacities
Engine Lubrication
Fuel System
Cooling System
Air Induction System
Transmission Lubrication
Mechanical Front Drive (MFD) Axle
2WD Front Wheel Bearings
Front PTO Lubrication
Operators Cab
-MAINTENANCE/ADJUSTMENTS
Cooling System
Fan/Alternator Belt And Compressor Belt
Operators Cab
Brakes
Engine Clutch
Adjusting The Automatic Hitch
Valve Clearences
-ELECTRICAL SYSTEM
Specifications
General Service Information
Fuses
Battery
Bulb And Lamp Replacement
MACHINE STORAGE
-SPECIFICATIONS
General Machine
Diesel Engine
Travel Speeds
Speed Chart Adjustment For Alternative Tires
Approximate Tractor Measurements
Approximate Tractor Weights
Noise Levels
DETAIL INDEX
